Sanitary Level Gauge with Sample Valve
Reference: SV-7SL
Sizes available: 1/2", 1" (DN15, DN25)
End connections: butt-welded, tri-clamp, threaded
Body material: AISI 304, AISI 316L
Seal material: Teflon (PTFE)
Max. working pressure: 145psi (10bar)
Min. working pressure: vacuum
Glass tube: φ20
Temperature range: 14°F to 248°F (-10°C to 120°C)
Operation: round handle
INQUIRY
Sizes available: 1/2", 1" (DN15, DN25)
End connections: butt-welded, tri-clamp, threaded
Body material: AISI 304, AISI 316L
Seal material: Teflon (PTFE)
Max. working pressure: 145psi (10bar)
Min. working pressure: vacuum
Glass tube: φ20
Temperature range: 14°F to 248°F (-10°C to 120°C)
Operation: round handle
APPLICATION
SV-7SL sanitary level gauge is mainly applied to the tank equipments. The two same gauges or two different gauges are assembled on the tank so that the liquid condition or capacity can be observed and the sample can be extracted.
TECHNICAL DATA
| Body Material | AISI 304, AISI 316L |
| Seal Material | Teflon (PTFE) |
| Max. Working Pressure | 145psi (10bar) |
| Working Temperature | 14°F to 248°F (-10°C to 120°C) |
| Internal Finish | Ra 16 ~ 32µin (0.4 ~ 0.8µm), Ra 32µin as default. |
| External Finish | Ra 16 ~ 32µin (0.4 ~ 0.8µm), Ra 32µin as default. |
| End Connections | butt-welded, tri-clamp, threaded |
| Handle Types | round handle |
